Coming Soon! Call us to pre-order.
The MOON 761 has one job to perform, and it performs it with authority. This power amplifier effortlessly delivers delicate audio signals from a preamplifier to loudspeakers with absolute transparency and finesse.
-
MDCA – MOON Distortion-Cancelling Amplifier
-
No Global Feedback Design
-
MOON Transistors
-
Dual Mono Configuration
-
Monaural Mode Toggle Switch
-
MOONLink
-
Multicolour LED Indicator
Specifications
-
Output Power (Stereo 8 Ω)200 W
-
Output Power (Stereo 4 Ω)400 W
-
Output Power (Mono 8 Ω)600 W
-
Input Sensitivity1.1 V
-
Input Impedance47 kΩ
-
Gain31 dB
-
Frequency Response2 Hz – 100 kHz (+0 dB / –3 dB)
-
Crosstalk–116 dB
-
Signal-to-Noise Ratio117 dB
-
Total Harmonic Distortion + Noise (@ 1 W)0.002%
-
Total Harmonic Distortion + Noise (@ 200 W)0.001%
-
Intermodulation Distortion0.002%
-
Damping Factor800
-
Power Consumption (Idle)55 W
-
Power Consumption (Full Power Standby)50 W
-
Power Consumption (Low Power Standby)1.25 W
-
Shipping Weight79 lbs / 36 kg
-
Dimensions (width x height x depth)18.95 x 5.53 x 17.53 in
48.1 x 14 x 44.5 cm
