ROON CORE AND GREAT SOUNDING SERVER/STREAMER!
High-performance music server with superior audio grade SSD, and enhanced main board to process music data losslessly.
- Designed for ultimate Hi-Fi sound enjoyment
A dedicated music-oriented computer, all the designs and technologies are created for lossless sound enjoyment.
The audio source is crucial for a wholesome Hi-Fi audio system, to process the high-res music data; to integrate other audio gears; to keep the the essence of music, Rhein Z1 is qualified to fulfill all those audio tasks and can be a Roon Core to serve multi-room system, optimized by its operating system, VitOS.
- Expert thermal solution to reduce interference
The CNC processing chassis made of ingeniously aerospace Industrial grade aluminum alloy, fan-less technique, and the whole upper case as CPU heat-sink .
Firm as a music fortress, exquisite as a true craftsmanship, fan-less technique makes no machine noise, and adopting the whole upper case as CPU heat-sink can lower 15% thermal noise in result, silent angel for your ultimate music experience.
- Specially Built Main Board
Dedicated Circuit for Audio Usage
- Low noise technique and shorter transmission path for high quality music playback, having smoother and purer music processing.
- Ulltra-low CPU power consumption (as 6W) to reduce electrical noise from main processor, and make the signal transmission more stable.
High-Permeability EMI Absorber
- Adopting specially chosen EMI absorber embedded to eliminate high-frequency electrical noise from 1MHz to 100MHz in internal digital circuits and components, including DRAM, CPU, and so on.
- Exclusive Audio Grade SSD
Noise Reduction and Signal Optimization
- Supporting dual SSD, while using low power consumption M.2 SATA SSD can lower the electrical noise on power rail.
- The new internal storage board provides pure SSD power source, greatly reducing the SATA signal transmission path to only 2cm.
Customized Applications
- 250GB specialized SSD for system disk; 1TB and 2TB specialized SSD for data disk, up to 2 simultaneous zones for multi-room streaming application, also can function as a NAS(Network Attached Storage).
- As Roon Core
With high-efficiency OS, VitOS, to function as a Roon Core server to perform the HD music services to the fullest.
Rhein Z1 can work as a Roon Core server to optimize the digital streaming experience, and serve multi-room audio setup, all for ultimate sound enjoyment, make you immerse in a home concert.
- Optimal Audio Integration
As an exceptional music server to cooperate with other audio devices to optimize sound enjoyment.
Adopting 1000Mbps Ethernet interface, you can easily connect it to a audio switch or a NAS, also equipped with high sampling rate USB Audio port to connect to external DAC to process high-res music data.
- Product Specifications - Black ; Silver
(DC) 12V/3A at max
36W at max
USB Audio - supports up to DSD 11.2M (DSD256), but DoP (only up to DSD64, depends on DAC)
Native DSD up to DSD256
Extension
- USB3.0*1, USB2.0*2 for extra storage
1000Mbps Ethernet Port
- works well with high-performance NAS(Network Attached Storage)
- connecting to Gigabit LAN port of a router or audio switch
HDMI Port
- engineer test only (Do Not Use)
Power LED (Blue)*1
Operating 32 ~ 86 °F; Storage -4 ~ 158 °F
Operating: 10% ~ 90% RH (non-condensing)
Storage: 5% ~ 95% RH (non-condensing)
7.87(W) inch x 2.56(H) inch x 7.87(D) inch
8.27 Ibs
